Laser Marking Details

Click on the reference for details

Simple Usability keeps operators focused on production, not on the printer:
  • Touchscreen user interface has built-in tools and wizards that guide you through code creation, job set-up and changeover to reduce operator errors
  • Extra-large marking field enables accurate coding in multiple locations, enabling more content to be marked across a larger area
  • Print at speeds up to 500 characters/sec
  • Maximum line speed of 60 m/min (197 ft/min)
Uptime Advantage keeps productivity up and costs down:
  • Portable and lightweight, the 3020 is designed to aid simple changeover. Setting up for different size products takes less than 20 minutes by adjusting the 3020’s mobile stand
  • Long-life laser tube provides years of reliable operation
Delivering consistent high quality codes across a range of simple applications:
  • Scribing technology produces clear, high quality marks on both moving and stationary products
  • Internal laser cooling, built upon efficient laser design, does not require external air sources, saving money
  • Compact, self-contained design integrates nicely in existing production lines; the 3020 can be positioned in a variety of angles and heights

10-Watt CO2 Industrial Laser Marking System for Moderate to High Speed Applications

The Videojet 3140 10-Watt CO2 laser marking system is engineered to offer all of the performance features found in higher wattage Videojet lasers, but with a power source better matched for moderate line speed applications. Ideal for both simple and complex code requirements on a range of substrates including paperboard, glass, painted metal, paper labels, PET and other plastic materials. The 3140 offers flexibility to meet a broad range of applications in many food, beverage, cosmetics and pharmaceutical operations.

Versatile coding solution delivers high performance
  • Optimized control software automatically calculates the most efficient way to mark, achieving faster marking speed
Uptime Advantage helps keep productivity up and costs down:
  • Laser tube is designed with larger gas volume and system is optimized for air-cooling to provide operational life of over 45,000 hours
  • Optional IP65 makes printer suitable for harsh production environments without need for plant air
  • CLARiTY™ Laser Controller reduces operator errors helping to ensure products are coded correctly, and advanced productivity tools help identify the root cause of downtime events to help make sustainable process improvements
Engineered to precisely match your exact coding needs and integration requirements:
  • Two available laser wavelengths, three marking heads and thirteen lenses for optimal code quality on your specific materials
  • 32 standard beam delivery options for integrating the laser marking system into your packaging or filling equipment can help produce the best system uptime
  • Multiple communication options designed to help integrate the laser marking system into many different control systems
  • Detachable umbilical available in 3 lengths for easy integration and line changeover, plus focus finder tool for quick set up of accurate focal distance

30-Watt CO2 Industrial Laser Marking System for Moderate to High Speed Applications

The 3340 30-Watt laser marking system offers a powerful combination of performance and flexibility, delivering high quality marks on moderate to high speed lines. Designed to maintain the best quality codes on high speed lines. Virtually no font, code or graphic restrictions, makes the 3340 an ideal solution for marking complex codes to meet the demand of applications in food, beverage, cosmetics, pharmaceutical and extrusion industries. A diverse combination of marking heads, lenses and wavelength options delivers an industry leading 21 spot size variations to match a broad range of marking effects.

Uptime Advantage helps keep productivity up and costs down:
  • Laser tube designed with larger gas volume has optimized air-cooling to provide operational life of over 45,000 hours
  • Optional IP65 makes printer suitable for harsh environments without need for plant air
  • CLARiTY™ Laser Controller reduces operator errors, helping to ensure products are coded correctly and advanced productivity tools identify the root cause of downtime events to make sustainable process improvements.
Engineered for high performance and quality:
  • Highly focused laser beams achieve better performance (mark contrast) than other laser solutions without needing higher power
  • Three available laser wavelengths, four marking heads and thirteen lenses for optimal code quality on your specific materials
  • High speed communication and buffering of variable data content delivers improved character formation, over other laser solutions, for customers who don’t need top speed, allowing more time to engage the product, resulting in crisp, legible codes
Flexibility and simple usability comes as standard:
  • Largest marking field in the industry (up to 600mm width) offers optimally matched applications for faster marking, increasing discrete product throughput or marking multiple messages across a wide web application using only one laser
  • 32 standard beam delivery options for integrating the laser marking system into your packaging or filling equipment can help produce the best system uptime
  • Focus finder tool for quick set up of accurate focal distance and detachable umbilical for easy integration and line changeover

60-Watt CO2 Industrial Laser Marking System for Moderate to High Speed Applications

The 3640 60-Watt CO2 laser marking machine is engineered to help address high-speed and high-volume applications in the pharmaceutical, tobacco and beverage markets. It is a compact high-speed laser system, and has been designed to process complex codes at high speeds, with the industry’s widest mark field.

Uptime Advantage helps keep productivity up and costs down:
  • Increase throughput with 60 watts of power, optimized for high-speed and high-volume production lines
  • Maximize printer availability with long-life, air-cooled laser sources that virtually eliminate maintenance intervals
  • Optional VideojetConnect™ Remote Service allows access to Videojet experts to help improve productivity and troubleshoot potential issues
Industrial design engineered for high performance:
  • Suitable for harsh environments, where dust and humidity are a challenge and where the system is regularly washed down
  • Available with an ingress protection level of IP65
  • Designed for 24/7 operation in beverage, food, pharmaceutical and tobacco line
Flexibility and simple usability comes as standard:
  • Compact, highest-powered laser marking system in the industry
  • Easily integrate the laser marking system even into production lines that have space limitations
  • Largest marking field reduces the number of lasers that are required to cover multi-lane / wide web applications, reducing investment and running cost

The Videojet 7220 10-Watt and Videojet 7320 20-Watt fiber laser marking systems are some of the most compact, versatile and low maintenance solid-state marking systems available. The 7220 and 7320 have been designed for direct parts marking and unique identification applications on metals, plastics and other hard to mark materials in the aerospace, automotive, electronics, medical devices and tools markets.

Specification
7220 7320
Laser Tube Solid State Fiber Solid State Fiber
Maximum Power 10W 20W
Laser Cooling Fan Fan
Maximum Line Speed 600 m/min (1968 ft/min) 600 m/min (1968 ft/min)
Environmental Protection IP21, IP54 (laser head) IP21, IP54 (laser head)
Beam Output Steered Beam Steered Beam
Laser Source Expected Life >100,000 hours >100,000 hours
Laser Wavelength Options 1.06 μm 1.06 μm
Focal Distance Options 50 mm (1.96 in) – 420 mm (16.53 in) 50 mm (1.96 in) – 420 mm (16.53 in)
Maximum Mark Window 498.5 x 361.5 mm (19.62 x 14.23 in) 498.5 x 361.5 mm (19.62 x 14.23 in)
Standard I/O Connectivity Internal Terminal Connections Internal Terminal Connections
Standard User Interface Handheld Handheld
Optional User Inteface PC, Touch Panel PC, Touch Panel
Plant Air Used No No
Certifications/Approvals CE CE

50-Watt Fiber Industrial Laser Printer for Marking on Robust Plastic and Metal Materials

The Videojet 7510 50-Watt fiber laser marking system delivers advantaged performance for high contrast marking on robust plastic packaging, metal containers and other industrial products even at ultra-fast line speeds up to 440m/min. Specifically engineered for high speed beverage, pharmaceutical and extrusion manufacturers, the 7510 delivers better mark quality, higher efficiency and a dramatically smaller marking unit than traditional solid state laser systems.

Specification
Value
Laser Tube Ytterbium (Yb) pulsed fiber laser
Maximum Power 50-Watt
Laser Cooling Air Cooled
Maximum Line Speed 440m/min (1440ft/min)
Environmental Protection Marking Unit: IP54
Supply Unit: IP21
Beam Output Steered Beam
Laser Source Expected Life (MTBF) Up to 100,000 hours (MTBF)
Laser Wavelength Options 1.06µm – 1.07µm
Focal Distance Options 100/163/254/420mm (3.93/6.41/10/16.53in)
Maximum Mark Window 498.5 x 366.5 mm (19.62 x 14.43 in)
Standard I/O Connectivity Internal Terminal Connections
Standard User Interface Smartgraph PC software
Optional User Inteface CLARiTY Laser Controller
Certifications/Approvals CE TUV

100-Watt Fiber Industrial Laser Printer for Marking highly legible, permanent codes at ultra-fast line speeds.

The Videojet 7610 100-Watt fiber laser marking system leverages the proven and extremely successful fiber product line from Videojet. The laser marking system now delivers extended speed capabilities to mark crisp, clear codes on robust plastic packaging, metal containers and other industrial products at up to 600m/min. The 7610 laser has been specifically engineered for high speed beverage, pharmaceutical, and extrusion manufacturers marking on robust materials such as high-density Polyethylene (HDPE), Nylon, Polyvinyl Chloride (PVC), as well as aluminum and stainless steel metals.

Specification
Value
Laser Tube Ytterbium (Yb) pulsed fiber laser
Maximum Power 100-Watt
Laser Cooling Air Cooled
Maximum Line Speed 600m/min (1968 ft/min)
Environmental Protection Marking Unit: IP54
Supply Unit: IP22
Beam Output Steered Beam
Laser Source Expected Life (MTBF) Up to 100,000 hours (MTBF)
Laser Wavelength Options 1.06µm – 1.07µm
Focal Distance Options 100/163/254/420mm (3.93/6.41/10/16.53in)
Maximum Mark Window 498.5 x 366.5 mm (19.62 x 14.43 in)
Standard I/O Connectivity Internal Terminal Connections
Standard User Interface Smartgraph PC software
Certifications/Approvals CE TUV

Videojet® 7340 /7440 Fiber Laser Marking Machines

Fiber Laser Marking Machines that fit the most restrictive spaces.

Developed to meet the needs of manufacturers who work within small spaces, the Videojet 7340 and 7440 fiber lasers feature the Lightfoot marking head, the most compact fiber laser marking head on the market.

Achieve easy integration and greater versatility in tight spaces with a fiber laser marking head that weighs less than 1kg / 2.2 lbs – the smallest and lightest fiber laser head on the market. Compact in size, the 7340 and 7440 fiber laser marking head can be easily integrated into production lines or complex machinery, allowing for an increased range of laser installation opportunities.

Benefit from a versatile fiber laser solution that is fast to set up, with virtually no consumables. Reduced mounting bracketry offers easy adjustment of the fiber laser marking head, aiding faster set-up and repositioning of the laser head.

Featuring a pilot beam-based focal alignment installation process, the 7340 and 7440 offer easier, faster and more precise installation. Control the 7340 and 7440 fiber lasers through a range of familiar, easy-to-use Videojet interfaces, ensuring seamless operation within your production line.

Specification
7340 7440
Laser Tube Solid State Fiber Solid State Fiber
Maximum Power 20W 30W
Laser Cooling Fan Fan
Maximum Line Speed 900 m/min (2,940 ft/min) 900 m/min (2,940 ft/min)
Environmental Protection IP21, IP69 (laser head) IP21, IP69 (laser head)
Beam Output Steered Beam Steered Beam
Laser Wavelength 1.04 – 1.09μm 1.04 – 1.09μm
Focal Distance Options 72 – 188 mm (2.83 – 7.4 in) 72 – 188 mm (2.83 – 7.4 in)
Maximum Mark Window 126.3 x 64.46 mm (4.97 x 2.53 in) 126.3 x 64.46 mm (4.97 x 2.53 in)
Standard I/O Connectivity Product Detect, Line Encoder, Fume Extraction Product Detect, Line Encoder, Fume Extraction
Optional User Inteface TCS+, CLARiTY™ Laser Controller, Smart Graph TCS+, CLARiTY™ Laser Controller, Smart Graph
Plant Air Used No No
Certifications/Approvals EtherNetIP DOC, ProfiNet/PNO certificate, CE EtherNetIP DOC, ProfiNet/PNO certificate, CE

Videojet® DN50A/LN100

High speed marking performance for greater productivity:

  • Capable of high quality marking at line speeds of up to 900 m/min (2950 ft/min) and 1300 characters/sec
  • Efficient production of marking jobs with text, machine-readable codes, graphics or other variable data

Meet the needs of a wide range of application solutions with superior laser beam quality and control:

  • The laser beam parameters can be adjusted to suit the job requirements for the best marking quality
  • Powerful software lets you create messages with automatically updated content, symbols, graphics and languages

Highly flexible integration:

  • Compact system design and innovative beam deliver system simplifies integration into production
  • Capable of being completely controlled by computer for use in fully automated production lines
  • Adaptable communication system makes print job development simpler and capable of being completed off-line
